Copper core cable for photovoltaic power generation Details

Product model

Model

Rated voltage

Conductor cross section

Name

Standard number

H1Z2Z2-K

AC:0.6/1kV;

DC:1.5kV

2.5-240mm²

Copper core cross-linked polyolefin insulated solar photovoltaic cable

prEN 50618: 2014

PV1-F

AC:0.6/1kV

DC:1.8kV

2.5-35mm²

2 Pfg 1169/08.2007



Product standards:

This product can be produced according to EU prEN 50618, 2 Pfg 1169/08.2007 or UL 4703 standard, and its performance meets the standard requirements.



Range of application:

It is used for the connection between solar cell modules and modules, the connection between the battery and the inverter, the connection between the battery array and the controller or the DC junction box.



Characteristic:

Equivalent to aluminum alloy photovoltaic cables.



Product specifications and important technical parameters

Section(mm²)

(Tinned copper)

Type of conductor

Insulation thickness

Approximate outer diameter

90°C Min Insulation Resistance  MQ.km

20°C Max Conductor Resistance  (Q2/km)

PV1-F

H1Z272-K

PV1-F

H1Z272-K

2.5

5

0.6

0.7

5.5

5.9

0.69

8.21

4

5

0.6

0.7

6.2

6.6

0.58

5.09

6

5

0.6

0.7

6.8

7.2

0.5

3.39

10

5

0.7

0.8

7.9

8.3

0.42

1.95

16

5

0.7

0.8

9.2

9.6

0.34

1.24

25

5

0.7

1.0

11.2

11.7

0.34

0.795

35

5

0.7

1.0

12.2

13.6

0.29

0.565



Current carrying capacity:

Nominal section(mm²)

Installation method(A)

Exposure to the air

Laying on the surface

Surface connection

 1.5

30

29

24

2.5

41

39

33

4

55

52

44

6

70

67

57



Nominal section(mm²)

Installation method(A)

Exposure to the air

Laying on the surface

Surface connection

10

98

93

79

16

132

125

107

25

176

167

142

35

218

207

176



Temperature deviation conversion factor

Ambient temperature (℃)

Below 60

70

80

90

100

110

Conversion factor

1.00

0.91

0.82

0.71

0.58

0.41
